SAC1 Waterproof Standalone Access Control /RFID EM Reader,Access Control
SAC1 Waterproof Standalone Access Control /RFID EM Reader Home > Access Control

SAC1 Waterproof Standalone Access Control /RFID EM Reader

INQUIRY
Waterproof Access Control/Card Reader, confirm to IP65
Stand Alone or Pass-through Operation
User Capacity:10,000
One Programmable Relay Operation
Card interface: 125KHz EM&HID Card or EM Card only
Remote Control for programming
Wiegand 26 input/output
2pcs SAC1 can be interlocked
Anti-pass back Function
Alam signal output, Door open detection
Toggle mode and Pulse mode
Multi-color LED status display
Operatin Voltage: 12VDC ±10%
Idle Current: <15mA
Read Range: 3-6cm
Wiring Connections: Relay Output,REX,DOTL,Alarm,Electric Lock,Wiegand
Relay: NO,NC,COM
Adjustable Relay Output Time: 1-99 secounds
Lock Output Load: 3Amp Maximum
Alam Output Load: 3Amp Maximm
Operating Temperature: -30℃~-60℃
Operation Humidity::0~95%(non-condensing)
Dimension:L103*W48*H21mm
