| Name | Access Control System |
| User Capacity | 3000(Fingerprint+Card+PIN) |
| Operation Voltage | +12V |
| Access Mode: | Fingerprint ,Card, PIN, Fingerprint & Card, Fingerprint & PIN |
| Fingerprint Reader Resolution Identification time FAR FRR |
Optical Fingerprint Module 500DPI <1S <0.0001% <0.01% |
| Proximity Card Reader Radio Technology Read Range |
Industry Standard 26 bits 125KHz Industry Proximity EM Card 2~7 cm |
| PIN Reader | 1~8 digits PIN |
| Wiring Connections | Relay Output, Exit Button, DOTL, Alarm, Wiegand output, Door Bell |
| Communication | USB TCP/IP USB for downloading/uploading |
| Output Adjustable Relay Output Time Lock Output Load Alarm Output Load |
MOS 1-99 Seconds (5 seconds default) 2 Amp Maximum 5 Amp Maximum |
| Wiegand Interface | Wiegand 26 bits Output |
| Environment Operating Temperature Operating Humidity |
Indoor -20℃~ 50℃ 20%RH-90%RH |
| Physical Dimensions Unit Weight Shipping Weight |
ABS Enclosure 300g 500g |
