Quick Details
• Lock Dimension:L340*W41*H21.5mm
• Armature Plate Dimension: L130*W33*H11.5mm
• Working Votage: DC12V / 520mA or DC24V/260mA
• Holding Force:180KG（350Lbs*2)
• Surface Temp: ≤ +10℃ (Based on ambient temperature)
• Operating Temp: -10~+55℃(14-131F)
• Humidity: 0~90%(non-condensing)
• Weight: 2.2KG
• Secure Type: Fail Safe
• Bracket Optional: B-180ZL/180Z/180L/180U
