SPS-02 Power Supply Support Backup Battery For Access Control, Lock, Door Video Phone System,Accessories
SPS-02 Power Supply Support Backup Battery For Access Control, Lock, Door Video Phone System Home > Accessories

SPS-02 Power Supply Support Backup Battery For Access Control, Lock, Door Video Phone System

INQUIRY



Uninterruptible power supply
Applicable to all types of access control systems, building interphone systems, alarm monitoring systems Power protection---Output over-voltage protection, over-current protection, short-circuit protection
Battery over-charging protection, over-discharging protection, anode & cathode wrong connect protection
AC failure & Battery low-voltage situation indicated by relay output


 Input: 190-240V AC
 Frequency: 50-60Hz
 Output voltage: DC 12V
 Output Current: 3A
 Over-current Protection: 3.6A
 Ripple & Noise less than 100mV
 Efficiency higher than 85%
 Charge Voltage: 13.5V
 Charge Current (Max. ): 1AMP
 Battery Under-voltage Protection: 10V
 Weight 1.2kg
 Dimensions:L203*W163*H74mm
